INOX PD97ES Electrified Mortise Lock with Auto-Locking And Monitoring

Model:

Write a review

Details: INOX PD97ES Electrified Mortise Lock with Auto-Locking And Monitoring

Sensor-controlled electrified Grade 1 mortise lock for sliding doors sends automatic signals that engage or retract bolt

Features

Built to easily integrate into all standard access control systems and monitoring terminals, the Grade 1 PD97ES uses REX, DBM, and DPS sensors that interact with any access control system on the market, allowing monitoring panels at every opening for extra security at crucial access points. The PD97ES is suited for a wide range of applications including but not limited to hospitality, healthcare, commercial, office, and residential.

Meets ANSI A117.1 Accessibility (ADA Compliant) and UL Standards for UL294 (Safety Access Control System Units), UL1034 (Safety Burglary-Resistant Electric Locking Mechanisms) and UL1784 (Smoke and Draft Control Door Assemblies).

Specifications

Standard Door Thickness: 1-3/4" (45mm) Standard 1-3/8" (35mm) with Thin Door Kit 2" to 2-1/4" (50mm to 57mm) Thick Door Kits available
Backset: 2-3/4" (70mm) and 2-1/2" (63.5mm)
Lever to Cylinder Center to Center: 3-7/8" (98mm)
Lever to Thumbturn Center to Center: 2-11/16" (68mm)
Handing: Specify handing
Cylinder: Schlage C keyway 6 pin 1-1/4" mortise with 2 keys; optional SFIC and LFIC housing and cores available
CAM: CAM01-SCL Clover Cam
Voltage: 12/24V DC
Max Voltage: 560 mA (lock body), 40 mA (strike)

Applications

Public Buildings & Facilities
Commercial & Industrial Buildings
Government & Military Facilities
Retail & Strip Malls
Multifamily & Mixed-Use

Compliance

UL1034 Burglary-resistant Electric Locking Mechanisms
UL294 Standard for Access Control System Units
ANSI/BHMA A156.25 Electrified Mortise Locks
ANSI/BHMA A156.18 Finishes
ANSI A117.1 ADA Accessibility

Downloads

HubSpot Video
null

Inox Unison Warranty

Available Model Numbers and Combinations

Model/SKU	Attributes
XGT318PD97ES80AC19RHCMB1146	Storeroom, Flat Black, 2 1/2", 2 1/16" Round, Cafe, Right Hand, 1-1/4" Cylinder, 6 pin, Not Included
XGT319PD97ES60A32RHLGT02	Bright Stainless Steel, 2 1/2", Patio, 2 1/16" Round, Hampton, Right Hand, Less Cylinder, GT02
XGT320PD97ES53CDBLHCMB1146GT02	Entrance, 2 3/4", Ceramax Dark Bronze, 2 1/16" Round, Empire, Left Hand, 1-1/4" Cylinder, 6 pin, GT02
XGT345PD97ES80AC19GLHCMB1146	Storeroom, 2 1/2", Ceramax Graphite Black, 2 1/16" Round, Tokyo, Left Hand, 1-1/4" Cylinder, 6 pin, Not Included
XGT346PD97ES60AC19RHLGS04	Flat Black, 2 1/2", Patio, 2 1/16" Round, Osaka, Right Hand, Less Cylinder, GS04
XGS201PD97ES60C19LHLGS02	Flat Black, 2 3/4", Patio, 2 3/16" Square, Cologne, Left Hand, Less Cylinder, GS02
XGS205PD97ES60CGYRHLGT04	2 3/4", Patio, Stormy Grey, 2 3/16" Square, Frankfurt, Right Hand, Less Cylinder, GT04
XGS205PD97ES60C19GRHLGT04	2 3/4", Patio, Ceramax Graphite Black, 2 3/16" Square, Frankfurt, Right Hand, Less Cylinder, GT04
XGS221PD97ES60CDBLHLGS07	2 3/4", Patio, Ceramax Dark Bronze, 2 3/16" Square, Aurora, Left Hand, Less Cylinder, GS07
XGS244PD97ES53C19LHCMB1146GT07	Flat Black, Entrance, 2 3/4", 2 3/16" Square, Twilight, Left Hand, 1-1/4" Cylinder, 6 pin, GT07
XGS276PD97ES53CDBRHCMB1146GT07	Entrance, 2 3/4", Ceramax Dark Bronze, 2 3/16" Square, Plaza, Right Hand, 1-1/4" Cylinder, 6 pin, GT07
XGS276PD97ES60A32DRHLGS07	2 1/2", Patio, Satin Stainless Steel, 2 3/16" Square, Plaza, Right Hand, Less Cylinder, GS07
XGT201PD97ES5332DLHCMB1146GS02	Entrance, 2 3/4", Satin Stainless Steel, 2 1/16" Round, Cologne, Left Hand, 1-1/4" Cylinder, 6 pin, GS02
XGS318PD97ES80ACGYLHCMB1146	Storeroom, 2 1/2", Stormy Grey, 2 3/16" Square, Cafe, Left Hand, 1-1/4" Cylinder, 6 pin, Not Included
XGS319PD97ES5332LHCMB1146GT07	Bright Stainless Steel, Entrance, 2 3/4", 2 3/16" Square, Hampton, Left Hand, 1-1/4" Cylinder, 6 pin, GT07
