  6. Legacy Manufacturing 7353 Security Automatic Door Bottom (9/16" by 1-7/8")
Legacy Manufacturing 7353 Security Automatic Door Bottom (9/16" by 1-7/8") View larger

Legacy Manufacturing LLC

Legacy Manufacturing 7353 Security Automatic Door Bottom (9/16" by 1-7/8")

Item is normally in stock and ships out within 2-3 Business days (excluding transit time). If out of stock it can take up to 2-4 weeks (excluding transit time).Specific options may or may not increase shipping time. For any reason, if there is a delay in shipping time we will notify you. Feel free to contact us if you have any concerns.

$353.78

Details: Legacy Manufacturing 7353 Security Automatic Door Bottom (9/16" by 1-7/8")

Features

  • Can be made any size from 12" to 144"
  • Designed to drop like a scissor (hinge side first then self-leveling to compensate for uneven floors)
  • 5 million cycles tested
  • Solid Rubber Extrusion is Black
  • Screws are standard (8 × 1-1/2" SMS self-drilling screws) supplied
  • Brass Hex Nut
  • Adjusting the brass nut changes pressure on concealed internal spring to satisfy field conditions.
  • Self-leveling door seal up to maximum 1" drop.
  • Replacement neoprene - Part 4053N or optional Part 4441N
  • Unit supplied standard with 1 pair of end caps - Part 4153EC-AP.
  • Fire-Rated - 7353 is fire-rated.
  • Acoustical ratings are achieved by OEM testing using specific door assembly configurations.

Specifications

LS
Light Spring
SF
Security Fasteners

Applications

  • Public Buildings & Facilities
  • Commercial & Industrial Buildings
  • Government & Military Facilities
  • Retail & Strip Malls
  • Multifamily & Mixed-Use

Downloads

Cut Sheet
