Camden Door Control CX-33 Advanced Logic Relay

Model: CX-33

Write a review

Item is normally in stock and ships out within 3-5 Business days (excluding transit time). If out of stock it can take up to 2-4 weeks (excluding transit time).Specific options may or may not increase shipping time. For any reason, if there is a delay in shipping time we will notify you. Feel free to contact us if you have any concerns.

Details: Camden Door Control CX-33 Advanced Logic Relay

Camden's CX-33 is a 'state of the art' logic relay designed to support virtually any automatic door application. The CX-33 features 15 operating modes, with sub-modes, and easy programming with large LCD display and push button selection.

Programmable modes include up to 3 door sequencing, airlocks, lock-out-relay, fire door in stairwells, and for control of automatic operators in restroom applications, with support of illuminated indicator of occupancy status.

Features

Ideal for most automatic door applications, as well as air lock and other security applications.
15 operating modes, with sub-modes. Selection and configuration with 3 push buttons.
Easily sequence multiple inputs with multiple maintain and hold outputs.
Large 3 segment (blue) LED display.
Selectable time delays, with delay on input activation.
Tried and true power circuitry ensures outstanding power filtering and surge protection.
Larger terminal strips allow larger wire gauge, or more conductors to be connected.
Clear plastic case provides better protection of circuit board and easy mounting.
12/24V AC/DC.

Specifications

Time Delay (Delay on Activate): 0-10 Seconds.
Voltage: 12 to 30V AC/DC.
Current Draw: 105 mA Typical, 320 mA Maximum.
Response Time: .5 Seconds.
Display: Blue LED: 1 Alpha/Numeric and 2 X 7-Segment.
Input: 4 x Dry1 X Wet: min. 4.5V AC/DC.
Output: 3 X Form C (SPDT).
Contact Rating: 3 A 24 VDC.
Temp Range: minus 22 Degree F to plus 185 Degree F (minus 30 Degree C to plus 85 Degree C).
Electrical Life: 100,000 Operations Rated Capacity.
Time Delay (Hold 1 timer): 0-50 Seconds.
Time Delay (Delay 1 Timer): 0-15 Seconds.
Time Delay (Hold 2 timer): 0-50 Seconds.
Time Delay (Delay 2 timer): 0-60 Seconds.
Time Delay (Hold 3 Timer): 0-50 Seconds.
Dimensions: 2" L X 6" W X 7/8" H (51mm X 152mm X 22mm).
Mounting: 2 X Number 6 Screws or Velcro.

Applications

Public Buildings & Facilities
Commercial & Industrial Buildings
Government & Military Facilities
Retail & Strip Malls
Multifamily & Mixed-Use
