  6. 9973-24Vx ETMVx 03x RHR Series Mortise Lock Exit Device w/ ET Trim & Standard, Coastal, Studio Lever
Reduced price! Sargent ET 9900 Series Mortise Lock Exit Device w/ Standard, Coastal, Studio Levers View larger

Sargent

Previous Next

9973-24Vx ETMVx 03x RHR Series Mortise Lock Exit Device w/ ET Trim & Standard, Coastal, Studio Lever

9973-24Vx ETMVx 03x RHR

Handing
Right Handed Reverse
edit options

Item normally ships out within 4-6 Weeks (excluding transit time). Specific options may or may not increase shipping time. For any reason, if there is a delay in shipping time we will notify you. Feel free to contact us if you have any concerns.

$2,457.75

40% Off

$4,096.25

?

Details: 9973-24Vx ETMVx 03x RHR Series Mortise Lock Exit Device w/ ET Trim & Standard, Coastal, Studio Lever

The 90 Series exit device is ideal for historical preservation projects requiring additional security, all crossbar assemblies are brass, bronze, stainless steel or steel. Available in mortise configurations, with modular construction and few moving parts, the 90 Series exit device is maintenance-free and provides unsurpassed security for historical facilities.

Features

  • Crossbar style rail design
  • Can be masterkeyed or grand masterkeyed with any other SARGENT product
  • Coordinates with lever, escutcheon trim and a variety of pull trims
  • ADA Compliant
  • Security: Multiple security features provide additional resistance against vandalism and unauthorized entry
  • Aesthetics: Traditional crossbar design creates an attractive design for places of worship and historical buildings. Available in many architectural finishes to blend with any decor

Specifications

For Doors
Wood or metal. 1-3/4" (44.5mm) thick standard. 4-1/2" (114mm) minimum stile Mounting Supplied standard with wood and machine screws.
Through-bolts available on order.
Chassis Cover
Brass, bronze or stainless steel
Chassis
Nonferrous alloy
Crossbar
1" brass, bronze and stainless steel tubing. Specify 42- for reinforced cross bar.
Hand
Handed, please specify hand when ordering
Mortise Lock
900 Series Mortise Lock, non-reversible
Dogging
Standard Allen key dogging (Not available on fire rated devices)
Strike
C908 standard for panic and fi re rated
Certification/Compliance ANSI
ANSI/BHMA156.3 - 2014 Grade 1 ADA Compliant

Applications

  • Public Buildings & Facilities
  • Commercial & Industrial Buildings
  • Government & Military Facilities
  • Retail & Strip Malls
  • Multifamily & Mixed-Use

Downloads

Available Model Numbers and Combinations

Model/SKUAttributes
9973-24Vx ETMGx 10x LHR MG Aventura, Left Handed Reverse
9973-24Vx ETMHx 20Dx RHR MH Odeon, Right Handed Reverse
9973-24Vx ETMVx 03x RHR Right Handed Reverse
9974-12Vx ETPRKx WSPx RHR White Suede Powder Coat, Right Handed Reverse
9915x ETLx 10BEx RHR Trim Always Operable, L Lever, Right Handed Reverse
9976-12Vx ETNJx 10BLx RHR NJ Centro, Right Handed Reverse
9976-12Vx ETMAx 10x RHR MA Notting Hill, Right Handed Reverse
9976-12Vx ETMIx 20Dx LHR MI Aventura, Left Handed Reverse
9976-24Vx 09x RHR Right Handed Reverse
9976-24Vx ETLx 20Dx RHR L Lever, Right Handed Reverse
994x ETMWx 10BLx LHR Key Retracts Latchbolt, MW Aventura, Left Handed Reverse
9974-24Vx ETMCx 10BLx RHR Right Handed Reverse
9910x ETAx 10BEx LHR A Lever, Left Handed Reverse
9910x ETJx 10BEx LHR J Lever, Left Handed Reverse
9974-24Vx ETMMx 20Dx LHR Left Handed Reverse
