  6. Stanley QMS100 QMS158-626 MDC SC6 KD Series Grade 1 Heavy Duty Mortise Lock
Reduced price! Stanley QMS100 Series Grade 1 Heavy Duty Mortise Lock View larger

Stanley Commercial Hardware

Stanley QMS100 QMS158-626 MDC SC6 KD Series Grade 1 Heavy Duty Mortise Lock

QMS158-626 MDC SC6 KD

edit options

Item is normally in stock and ships out within 2-3 Business days (excluding transit time). If out of stock it can take up to 2-4 weeks (excluding transit time).Specific options may or may not increase shipping time. For any reason, if there is a delay in shipping time we will notify you. Feel free to contact us if you have any concerns.

$141.55

40% Off

$235.92

Details: Stanley QMS100 QMS158-626 MDC SC6 KD Series Grade 1 Heavy Duty Mortise Lock

Applications

  • The heavy duty QML100 series mortise locks are designed for institutional and commercial uses such as educational, health care and industrial facilities where a long-lasting, highly durable product is required.

Performance Features

  • Tested to exceed 2,000,000 cycles, surpassing the 1,000,000 required to meet Grade 1 certifcation.
  • Patented clutching mechanism standard.
  • Thru-Bolt design and heavy-duty spring tension provides longer performance life and prevents lever sag.
  • ADA compliant thumbturn.
  • Mortise case is easily field reversible.
  • Pre-assembled trims with spring loaded spindles automatically adjust to door thickness and reduces installation time.
  • Partial security seperator prevents spindle manipulation.
  • Anti-friction throwbolt.

Certifications

  • ANSI/BHMA A156.13 - Grade 1
  • UL/cUL listed (3-hours) for "A" label single door applications (4'x8")
  • UL10C/UBC 7-2 (1997) Positive Pressure Rated
  • UL10B Pressure Rated
  • ADA Compliant ANSI A117.1 Accessibility Code
  • California State Reference Code (formerly Title 19 - Fire Marshall)

Product Specifications

  • Solid forged brass trim construction.
  • Dual 8mm spindles.
  • 1" (25.4mm) stainless steel dead bolt.
  • Floating mounting tabs adjust to door bevel.
  • Toggle button locking.
  • Heavy gauge steel armor face plate.
  • Door Thickness - Sectional: 1 3?4"- 2" (44.5mm-51mm) standard; 2 1?4" (57mm) optional
    - Escutcheon: 1 3?4"- 2 1?4" (44.5mm-57mm) standard

Keying

  • 6-pin or 5-pin Cylinders. Many keying options available from our factory to include, but not limited to, master keying, grandmaster keying, and construction keying. Small Format Interchangeable Core cylinder also available.
  • 2 keys per lockset.
  • Offered with the following keyway options: KW-Kwikset, WE-Weiser, SC-Schlage, GA-Yale, LA-Sargent, BF-Best "F" & LC-Less Cylinder
