> >>>>Hafele 361.81.912 Badge Center Door Hinge, Zinc Die-Cast, Unhanded
Hafele 361.81.912 Badge Center Door Hinge, Zinc Die-Cast, Unhanded View larger

Hafele

Hafele 361.81.912 Badge Center Door Hinge, Zinc Die-Cast, Unhanded

361.81.912

Item normally ships out within 1-2 Weeks (excluding transit time). If out of stock it can take up to 3-4 weeks (excluding transit time). Specific options may or may not increase shipping time. For any reason, if there is a delay in shipping time we will notify you. Feel free to contact us if you have any concerns.

$21.75

Details: Hafele 361.81.912 Badge Center Door Hinge, Zinc Die-Cast, Unhanded

Features

  • Stylish design for inset doors

Specifications

Version
With catch
Material
Zinc alloy
Color/finish
Aluminum colored
For glass thickness
4-6 mm
For glass thickness (inches)
5/32"-1/4"
Door processing for assembly
without glass drilling
Door width max.
400 mm
Door width max.
15 3/4"
Door height max.
1000 mm
Door height max.
39 3/8"
Installation
Edge mounts to glass door with one ABS plastic screw

Applications

  • Public Buildings & Facilities
  • Commercial & Industrial Buildings
  • Government,
  • Retail & Strip Malls
  • Multifamily & Mixed-Use
