Precision 200 Series Crossbar Surface Vertical Rod Exit Device - Non Handed

Cylinder Not Included

Item normally ships out within 2-4 Weeks (excluding transit time). Specific options may or may not increase shipping time. For any reason, if there is a delay in shipping time we will notify you. Feel free to contact us if you have any concerns.

$2,165.25

50% Off

$4,330.49

?

Details: Precision 200 Series Crossbar Surface Vertical Rod Exit Device - Non Handed

Olympian 200 Series - Non Handed

Olympian FL200 Fire Exit Series - Non Handed

Features

Doors
For all types of single and double door applications. Available for 1-3/4" to 2-1/4" thick, up to 4'-0" wide by 10'-0" high openings. For thicker doors, consult factory. Furnished standard for 1-3/4" thick, 3'-0" wide by 7'-0" high openings.
Device
Covers ANSI A115.2 (Type 161), A115.18 cylinder lock and A115.1 (Type 86) Mortise Lock preparation.
Functions
Functions are field selectable. The device is furnished for a desired function if specified. If not specified the "03" function is furnished standard.
Covers
Lock Stile and Hinge Stile Assembly, Cold drawn Bronze, Brass, Stainless Steel.
Chassis
Lock Stile and Hinge Stile Assembly, Investment Cast Steel, Zinc Dichromated.
Arms
Forged Brass or Bronze.
Crossbar
1 Bronze, Brass or Stainless Steel tubing furnished standard for a 3-0 Door. For wider doors, specify door width. Knurled and Reinforced crossbars are available.
Vertical Rods
Brass, Bronze or Stainless Steel.
Top Latchbolt
Stainless Steel, Deadlocking, 3/4" throw.
Bottom Bolt
Steel plated, independent action 5/8" throw, with adjustment range to suit 3/4 door undercut.
Top Strike
No. S300, Investment Cast Stainless Steel, Black Powder Coated.
Bottom Strike
No. S460, Steel, Black Powder Coated, flush mounted.
Crossbar Height
34-5/8" to centerline from finish floor standard. May be varied as situation dictates, consult factory.
Dogging
Hex Key dogging standard for Panic Hardware. NOT available on Fire Exit Hardware.
UL Listed
Panic and Fire Exit Hardware. For FIRE EXIT HARDWARE Ratings see page 15. Conforms to UL10C and UBC 7-2.
ANSI/BHMA
Devices are BHMA certified for ANSI 156.3, Grade 1.
Finishes
605, 606, 612, 613, 625, 630
Cylinders
Rim Type, not furnished standard. Specify when required. For cylinder details see page 13.
Stile Width
See Stile Information on page 14.
Less Bottom Rod (LBR) Option
Specify suffix "LBR" (e.g. 208LBR). See UL FIRE LABEL RATING Chart on page 15. Fire Rated Devices include FB277 Fire Bolt Assembly.
