Entrematic HA8-LP Series, Surface Mount Low Energy Ditec Door Operator

WL-

Item normally ships out within 1-2 Weeks (excluding transit time). If out of stock it can take up to 3-4 weeks (excluding transit time). Specific options may or may not increase shipping time. For any reason, if there is a delay in shipping time we will notify you. Feel free to contact us if you have any concerns.

$3,787.20

10% Off

$4,208.00

Details: Entrematic HA8-LP Series, Surface Mount Low Energy Ditec Door Operator

The Ditec HA8-LP low-energy operator has the same power and durability of the standard profile, but with a smaller header for applications where clearance is limited. The low-profile is available as surface applied, and can be found in hospitals, retail stores, schools & universities, airports, convention centers, casinos, industrial buildings and offices.

Features

  • High precision gears made for sustained long-term use.
  • Electro Mechanical Design for simple dependable operation.
  • Permanent lubrication for maintenance free operation.
  • Machined alloy gearbox housing.
  • 1/8th HP motor.
  • Digital Control Board.
  • Built to outlast the competition.
  • Perfect for high traffic locations.

Specifications

Header Profile Dimensions
4 1/8" × 5 1/8"
Motor
1/8 HP
Manual Opening/Closing Force
Adjustable 5 to 30 lbs
Push Reveal
Up to 14"
Pull Reveal
Up to 5"
Total Weight with 39" Header
44 lbs
Non-Handed
Available in push or pull

1 Ditec HA8-LP Complete Install

Applications

  • Public Buildings & Facilities
  • Commercial & Industrial Buildings
  • Government & Military Facilities
  • Retail & Strip Malls
  • Multifamily & Mixed-Use

Available Model Numbers and Combinations

Model/SKUAttributes
WL-102-39 CL Clear, 39", Left Hand Pull, 36" Single, Not Included,
WL-106-39 BZ Bronze, 39", Left Hand Pull, 36" Single, Not Included,
WL-101-39 CL Clear, Push, 39", 36" Single, Not Included,
WL-105-39 BZ Bronze, Push, 39", 36" Single, Not Included,
WL-104-39 CL Clear, 39", Right Hand Pull, 36" Single, Not Included,
WL-108-39 BZ Bronze, 39", Right Hand Pull, 36" Single, Not Included,
WL-102-45 CL Clear, 45", Left Hand Pull, 42" Single, Not Included,
WL-106-45 BZ Bronze, 45", Left Hand Pull, 42" Single, Not Included,
WL-101-45 CL Clear, Push, 45", 42" Single, Not Included,
WL-105-45 BZ Bronze, Push, 45", 42" Single, Not Included,
WL-104-45 CL Clear, 45", Right Hand Pull, 42" Single, Not Included,
WL-108-45 BZ Bronze, 45", Right Hand Pull, 42" Single, Not Included,
WL-102-51 CL Clear, 51", Left Hand Pull, 48" Single, Not Included,
WL-106-51 BZ Bronze, 51", Left Hand Pull, 48" Single, Not Included,
WL-101-51 CL Clear, Push, 51", 48" Single, Not Included,

View All Model Numbers and Options
