PDQ 6400V Surface Vertical Rod Narrow Stile Exit Device

64

Item normally ships out within 1-2 Weeks (excluding transit time). If out of stock it can take up to 3-4 weeks (excluding transit time). Specific options may or may not increase shipping time. For any reason, if there is a delay in shipping time we will notify you. Feel free to contact us if you have any concerns.

$906.60

40% Off

$1,511.00

Details: PDQ 6400V Surface Vertical Rod Narrow Stile Exit Device

Narrow Stile SVR exit device with 3/4" toggle latch top and 5/8" travel drop bolt on the bottom. Use for narrow stile double door applications, or when a narrow look is preferred.

Features & Benefits

  • Cast chassis support for increased strength
  • Cush spring quiets in both directions
  • Compression spring for touch bar return
  • Heavy-Duty flush end cap for pry resistance
  • 6-Finishes: 605(US3), 606(US4), 613(US10B), 622(US19), 626(US26D), 630(US32D)
  • Patent Pending

Electrified Options

  • Motorized Latch Retraction
  • Request to Exit/Signal Switch
  • Alarmed Exit
  • Latch Bolt Monitor
  • ISMC Connector

Certifications

  • UL 305
  • UL 10C and CAN/ULC-S104 listed 3-hour fire door, for double doors up to 8' × 8' (LBR), 8' × 10' (single or double egress pair)
  • Certified to ANSI/BHMA A156.3 Grade 1
  • FL #40297 +50/-50 psf 8080 18ga Pair
  • Complies with ADA (Americans with Disabilities Act) and ICC/ANSI 117.1 for Accessible and Usable Buildings
