Precision 300 Series Crossbar Mortise Exit Device - Handed

Cylinder Not Included

Item normally ships out within 2-4 Weeks (excluding transit time). Specific options may or may not increase shipping time. For any reason, if there is a delay in shipping time we will notify you. Feel free to contact us if you have any concerns.

$2,131.50

50% Off

$4,263.01

?

Details: Precision 300 Series Crossbar Mortise Exit Device - Handed

Olympian 300 Series - Handed

Olympian FL300 Fire Exit Series - Handed

Features

Doors
For all types of single and double door applications. Available for 1-3/4" to 2-1/4" thick, up to 4'-0" wide opening. For thicker doors, consult factory. Furnished standard for 1-3/4" thick, 3'-0" wide opening.
Device
Covers ANSI A115.1 (Type 86) Mortise Lock preparation.
Covers
Lock Stile and Hinge Stile Assembly, Cold drawn Bronze, Brass, Stainless Steel.
Chassis
Lock Stile and Hinge Stile Assembly, Investment Cast Steel, Zinc Dichromated.
Arms
Forged Brass or Bronze.
Crossbar
1 Bronze, Brass or Stainless Steel tubing furnished standard for a 3'-0" Door. For wider doors, specify door width. Knurled and Reinforced crossbars are available.
Dogging
Hex Key dogging standard for Panic Hardware. NOT available on Fire Exit Hardware.
Handed
Specify hand when ordering as RHRB or LHRB. Standard packaging is RHRB.
UL Listed
Panic and Fire Exit Hardware. For FIRE EXIT HARDWARE Ratings see page 15. Conforms to UL10C and UBC 7-2.
ANSI/BHMA
Devices are BHMA certified for ANSI 156.3, Grade 1.
Finishes
605, 606, 612, 613, 625, 630
Cylinders
Mortise type, not furnished standard. For cylinder details see page 13.
Stile Width
See Stile Information on page 14.
Crossbar Height
34-5/8" to centerline from finish floor standard. May be varied as situation dictates, consult factory.
Mortise Lock
Handed Fits doors machined per ANSI A115.1 for Federal Lock Type 86.
Backset
2-3/4"
Case
Wrought Steel, Zinc Dichromate finish.
Lock Front Plate
8" × 1-1/4" Bronze, Brass or Stainless Steel, pivots for beveled or square edged doors.
Latchbolt
Stainless Steel, Deadlocking, 3/4" throw, anti-friction.
Guardbolt
Stainless Steel, sliding type.
Finishes - LOCK FRONT PLATE and STRIKE
605, 606, 612, 613, 625, 630
Strikes
No. S982 handed curved lip strike standard. For optional strikes see page 10.
Lock No
M303 for 01, 02 and 03 functions. M308 for 05, 05A, 08 and 08A functions.

Documentation

Available Model Numbers and Combinations

Model/SKUAttributes
301FC-LD-SNB-RHRB-613S458x4'-0"x9'-0"x1-7/8" Not Included, Included, Not Included, Satin Bronze, Oxidized, Oil Rubbed, 4'-0", 1-7/8"
301CBR-SNB-LHRB-625S988x3'-0"x7'-0"x2-1/4" Included, Not Included, Not Included, 3'-0", 2-1/4"
301FC-LD-SNB-RHRB-613S988x3'-0"x9'-0"x2-0" Not Included, Included, Not Included, Satin Bronze, Oxidized, Oil Rubbed, 3'-0", 2-0"
301RHRB-630S988x4'-0"x8'-0"x2-1/8" Not Included, Not Included, Not Included, Not Included, Satin Stainless Steel, 4'-0", 2-1/8"
301FC-LD-SNB-RHRB-606S300x4'-0"x7'-0"x2-0" Not Included, Included, Not Included, 4'-0", 2-0"
301FC-LD-SNB-RHRB-606S458x3'-0"x7'-0"x2-1/4" Not Included, Included, Not Included, 3'-0", 2-1/4"
301CBR-SNB-LHRB-612S300x3'-0"x10'-0"x1-3/4" Included, Not Included, Not Included, 3'-0", 1-3/4"
301FC-LD-SNB-RHRB-606S458x2'-6"x8'-0"x2-0" Not Included, Included, Not Included, 2-0"
301RHRB-613S300x2'-6"x7'-0"x2-1/8" Not Included, Not Included, Not Included, Not Included, Satin Bronze, Oxidized, Oil Rubbed, 2-1/8"
301CBR-SNB-LHRB-612S458x4'-0"x12'-0"x2-0" Included, Not Included, Not Included, 4'-0", 2-0"
301FC-LD-SNB-RHRB-605S988x3'-0"x11'-0"x1-7/8" Not Included, Included, Not Included, 3'-0", 1-7/8"
301CBR-SNB-LHRB-606S300x4'-0"x12'-0"x2-1/8" Included, Not Included, Not Included, 4'-0", 2-1/8"
301FC-LD-SNB-LHRB-630S458x3'-0"x12'-0"x1-3/4" Not Included, Included, Not Included, Satin Stainless Steel, 3'-0", 1-3/4"
301FC-LD-SNB-LHRB-630S458x2'-6"x9'-0"x2-1/4" Not Included, Included, Not Included, Satin Stainless Steel, 2-1/4"
301CBR-SNB-LHRB-606S988x3'-0"x10'-0"x2-0" Included, Not Included, Not Included, 3'-0", 2-0"
