SECO-LARM SD-9163 Outdoor Wave-to-Open Sensor

Item is normally in stock and ships out within 2-3 Business days (excluding transit time). If out of stock it can take up to 2-4 weeks (excluding transit time).Specific options may or may not increase shipping time. For any reason, if there is a delay in shipping time we will notify you. Feel free to contact us if you have any concerns.

$49.60

Details: SECO-LARM SD-9163 Outdoor Wave-to-Open Sensor

The ENFORCER Outdoor Wave-to-Open Sensor is a full-featured exit plate using IR technology to allow egress from a protected area or activate a device with the simple wave of a hand. Since no touch is required, this sensor is suitable for use in hospitals, clinics, labs, cleanrooms (to reduce the risk of contamination), schools, factories, or offices.

Features

  • ETL, Conforms to UL Std. 294
  • Adjustable sensor range up to 7" (18cm)
  • 1.2A relay, adjustable trigger duration 0.5-30 seconds or toggle
  • LED illuminated sensors are for easy identification
  • Selectable LED colors turn from red to green (or green to red) when the sensor is activated
  • Stainless steel plate
  • IP65 Weather-resistant for outdoor use
  • Power must be provided by low-voltage power-limited/Class 2 power supply
  • Use only low-voltage field wiring and do not exceed 98.5 ft (30m) activated

Specifications

Operating temperature
12-24 VDC
Current draw (max. +or-10%) Standby red
(12/24 VDC): 13mA / 15mA
Current draw (max. +or-10%) Triggered green
(12/24 VDC): 21mA / 25mA
Current draw (max. +or-10%) Standby green
(12/24 VDC): 12mA / 14mA
Current draw (max. +or-10%) Triggered red
(12/24 VDC): 23mA / 28mA
Relay type
SPDT dry contact, 1.2A@24VDC
Response time
10ms
LED Standby
Red
LED Triggered
Green
Output duration
0.5-30 s, toggle
Range
2"-7" (5-18 cm)
Destructive attack level
Level I
Line security
Level I
Endurance level
Level IV
Standby power
Level I
IP Rating
Weatherproof, IP65
Operating Temperature
-4Degree-131Degree F (-20Degree-55Degree C)
Dimensions
1-1/2" x4-1/2"(39 x115 mm)
Weight
2.2-oz (61g)

Applications

  • Public Buildings & Facilities
  • Commercial & Industrial Buildings
  • Government & Military Facilities
  • Retail & Strip Malls
  • Multifamily & Mixed-Use

Downloads

Available Model Numbers and Combinations

Model/SKUAttributes
SD-9163-KSQ
SD-9163-KSVQ
SD-9163-KS1Q
