Details: Precision 2800 Concealed Vertical Rod Exit Device - Reversible, Wide Stile

Features

Doors

For all types of metal single and double door applications. Available for 1-3/4" thick, up to 4'-0" wide by 10-0 high openings. For thicker doors, consult factory. Furnished standard for 1-3/4" thick, 3'-0" wide by 6'-8" to 8'-0" high openings.

Functions

Functions are field selectable. The device is furnished for a desired function if specified. If not specified the "03" function is furnished standard.

Base Material

The Cover, Touchbar, Device Channel, Lock/Hinge Side Filler and End Cap are furnished of heavy wrought Brass, Bronze or Stainless Steel. US28 Devices are furnished with Aluminum, Brass, Bronze and Stainless Steel components. See "Base Material and Finish Chart" on page 3.

Chassis

Lock Stile Assembly - Investment Cast Steel, Zinc Dichromated.

Vertical Rods

Steel, plated. Top Rod is adjustable from 6'-8" to 8'-0" or from 8'-1" to 10'-0". Additional adjustments are available through the lock front filler.

Top Latchbolt

Stainless Steel, Deadlocking, 3/4" throw.

Top Strike

No. S519 Surface applied, Investment Cast Stainless Steel, Black Powder Coated.

Bottom Bolt

Steel plated, independent action 5/8" throw, with adjustment range to suit 3/4" door undercut.

Center Chassis

Steel plated, heavy wrought Steel Assembly with lock in place Top and Bottom Latch Adjustors. Adjustment accessible through the door after installation.

Bottom Strike

No. S460, Flush mounted, Steel, Black Powder Coated.

Dogging

1/4" turn hex key dogging standard. NOT available on Fire Exit Hardware.

Touchbar Height

39-15/16" from floor standard. Specify required height if other than standard.

Reversible

Reversible for all functions and trims.Standard packaging RHRB.

UL Listed

Panic and Fire Exit Hardware. For FIRE EXIT HARDWARE Ratings see page 33. Conforms to UL10C and UBC 7-2.

ANSI/BHMA

Devices are BHMA certified for ANSI 156.3, Grade 1.

Finishes

605, 606, 612, 613, 622, 625, 626W, 628, 630, 690

Cylinders

Rim Type, not furnished standard. Specify when required. For cylinder details see page 19.

Stile Width

See Stile Information on page 36.

Less Bottom Rod (LBR) Option

Specify suffix "LBR" (e.g. 2808LBR). See UL FIRE LABEL RATING chart on page 33. Fire Rated Devices include FB277 Fire Bolt Assembly. For Fire Bolt Assembly image see page 35.
