Reduced price! Sargent ET 8300 Series Narrow Design Mortise Lock Exit Device w/ Standard, Coastal, Studio Levers

View larger

Sargent 8300 Series Narrow Design Mortise Lock Exit Device w/ ET Control Trim & Standard, Coastal, Studio Lever

Model:

Write a review

Item normally ships out within 4-6 Weeks (excluding transit time). Specific options may or may not increase shipping time. For any reason, if there is a delay in shipping time we will notify you. Feel free to contact us if you have any concerns.

$2,545.89

40% Off

$4,243.15

Quantity

Fire Rated

Dogging Option

Latchbolt Monitoring Switch

Monitors ET Lever Movement

Request to Exit

Motorized Electric Latch Retraction

Electric Dogging

Electroguard

Alarmed Exit

Tactile Warning Option

SARGuide

MicroShield-Antimicrobial Powder Coat

Through Bolts

Lever Option

Function

Voltage

Rail

Choose a Finish

Handing

Details: Sargent 8300 Series Narrow Design Mortise Lock Exit Device w/ ET Control Trim & Standard, Coastal, Studio Lever

The 80 Series exit device is ideal for environments that require strong and durable security solutions. Made to last the lifetime of the building, this device easily exceeds ANSI/BHMA Grade 1 requirements for cycle and strength and is available in rim, mortise, surface vertical and concealed vertical rod configurations. With a modular design, this device has been crafted to be maintenance-free and provide unsurpassed security for any facility.

Features

Designed for standard width stiles with a narrow design look
Through-bolted trim for quiet operation and security
Single door applications
Double door applications with Mortise Lock × Vertical Rod Device
UL10C (Fire) and UL305 (Panic) listed
Devices are ANSI/BHMA A156.3 - Grade 1

Specifications

Door Type: Wood or metal doors
Door Thickness: 1-3/4" (44mm) minimum thickness. Stile 4-1/2" (114mm) minimum stile width
Rail sizes as determined by door Width: E Rail for 24" to 32" door widths, No cutting required for 32" door, F Rail for 33" to 36" door widths, No cutting required for 36" door, J Rail for 37" to 42" door widths, No cutting required for 42" door, G Rail for 43" to 48" door widths, No cutting required for 48" door
Strike: C908 Standard Black Nylon Coated - ANSI Prep A115.1
Dogging Feature: Hex key dogging standard on non fired rated devices; specify 16- for cylinder dogging (
Mounting Fasteners: Supplied standard with wood and machine screws
Latch Bolt: Brass Nickel Plated, 3/4" (19mm) throw, anti-friction
Guarded/Deadlatch: Brass, sliding type
Device Centerline from Finished Floor: 41" (1041 mm) for Standard Applications
Center Case Dimensions: 8-5/16" (211mm) × 1-1/16" (27mm)
Projection: Pushbar Neutral - 3" (76mm), Pushbar Depressed - 2-1/8" (54mm)

Applications

Public Buildings & Facilities
Commercial & Industrial Buildings
Government & Military Facilities
Retail & Strip Malls
Multifamily & Mixed-Use

Downloads

56- Latch Retraction in Power Mode

56- Latch Retraction in Timer Mode

Unboxing a 59- Electroguard Delayed Egress Exit Device

59- Electroguard Diagnostic LEDs

How to Change the Function on a SARGENT ET Lever Trim

Sargent Warranty

Available Model Numbers and Combinations

Model/SKU	Attributes
8343Jx 10BEx RHR	Key engages/disengages Lever, 37" to 42",
8376-12VEx ETMTx 10Bx RHR	24" to 32", MT Notting Hill,
8373-12VFx ETMYx WSPx RHR	33" to 36", White Suede Powder Coat,
8373-24VFx ETMXx 03x LHR	33" to 36",
8373-12VFx ETMBx 03x RHR	33" to 36", MB Aventura,
8376-24VJx ETRx 20Dx LHR	37" to 42", Rockport Lever,
8313Ex ETMPx 10BEx RHR	Key Locks/Unlocks Control, 24" to 32", MP Centro,
8343Jx ETMVx 10BEx LHR	Key engages/disengages Lever, 37" to 42",
8374-24VJx ETMWx 20Dx RHR	37" to 42", MW Aventura,
8375-24VGx ETMWx 10BLx LHR	43'' to 48", MW Aventura,
8373-24VJx ETGx 20Dx LHR	37" to 42", Gulfport Lever,
834Fx ETLx 20Dx RHR	Key Retracts Latchbolt (Lever Rigid), 33" to 36", L Lever,
8373-12VFx ETMGx 10Bx RHR	33" to 36", MG Aventura,
8374-12VJx ETMFx 09x RHR	37" to 42", MF Aventura,
8375-24VGx ETMSx 32Dx RHR	43'' to 48", Satin Stainless Steel,
